Drawing

The Drawing manages all necessary data that belong to a model.

On the one hand these are the structure and graphic data by which the CAD model is defined, on the other hand it administers additional data for the support with the client-sided development.

DrawingID#

DrawingAPI#

structure#

selection#

interaction#

plugin#

geometry#

graphic#

cad#

reset#

Declaration

() => void

Returns void

DrawingState#

Members

Name	Type	Description
api	DrawingAPI

createDrawingState#

StructureData#

Members

Name	Type	Description
products	ObjectID[]
visibleContainers	GraphicID[]

StructureApi#

get#

Declaration

(): StructureData

Returns StructureData

set#

Declaration

(structure: IStructureProtocol): void

Params

Name	Type	Default	Description
structure	IStructureProtocol

Returns void

applyPatches#

Declaration

(patches: IStructurePatch[]): void

Params

Name	Type	Default	Description
patches	IStructurePatch[]

Returns void

filterTree#

Declaration

(tree: IStructureTree, filter: (obj: IStructureObject) => boolean): IStructureObject[]

Params

Name	Type	Default	Description
tree	IStructureTree
filter	(obj: IStructureObject) => boolean

Returns IStructureObject[]

findTree#

Declaration

(tree: IStructureTree, filter: (obj: IStructureObject) => boolean): IStructureObject | undefined

Params

Name	Type	Default	Description
tree	IStructureTree
filter	(obj: IStructureObject) => boolean

Returns IStructureObject | undefined

collectUsedSolidIds#

Declaration

(): ObjectID[]

Returns ObjectID[]

collectProducts#

Declaration

(root: ObjectID): IStructureObject[]

Params

Name	Type	Default	Description
root	ObjectID

Returns IStructureObject[]

getProductSolidIds#

Declaration

(productId: ObjectID): any[]

Params

Name	Type	Default	Description
productId	ObjectID

Returns any[]

postProcessStructureUpdate#

Declaration

(): void

Returns void

calculateGlobalTransformation#

Calculates the global transformation matrix for the given objectId.

Declaration

(objectId: ObjectID, matrix: THREE.Matrix4 = new THREE.Matrix4().identity()): THREE.Matrix4

Params

Name	Type	Default	Description
objectId	ObjectID		The object to calculate the global transformation for.
matrix?	THREE.Matrix4	new THREE.Matrix4().identity()	The initial matrix (mainly used for recursion). It is an out parameter and in the end, it will contain the same matrix as the return value of this function.

Returns THREE.Matrix4
The global transformation matrix for the given objectId.

calculateProductBounds#

Declaration

(productId: ObjectID, base?: {
    min: THREE.Vector3;
    max: THREE.Vector3;
}): { center: THREE.Vector3; radius: number; max: THREE.Vector3; min: THREE.Vector3; }

Params

Name	Type	Default	Description
productId	ObjectID
base.min	THREE.Vector3
base.max	THREE.Vector3

Returns { center: THREE.Vector3; radius: number; max: THREE.Vector3; min: THREE.Vector3; }

getDrawingId#

This is a workaround to get the corresponding drawing id via API.

!!! Should not be used in user code !!!

Declaration

(): DrawingID

Returns DrawingID
The drawing id.

structureData#

structureApi#

GraphicData#

Members

Name	Type	Description
containers	Record<number, IGraphicContainer>

GraphicApi#

addPackages#

Declaration

(packages: IGraphicPackage[]): void

Params

Name	Type	Default	Description
packages	IGraphicPackage[]

Returns void

cleanupGraphicRecords#

Declaration

(): void

Returns void

filter#

Declaration

(cb: (elem: IGraphicElement) => boolean, options?: {
    onlyOne?: boolean;
    containerId?: ObjectID;
}): { elem: IGraphicElement; containerId: ObjectID; solidId: ObjectID; }[]

Params

Name	Type	Default	Description
cb	(elem: IGraphicElement) => boolean
options.onlyOne?	boolean
options.containerId?	ObjectID

Returns { elem: IGraphicElement; containerId: ObjectID; solidId: ObjectID; }[]

graphicData#

containers#

graphicApi#

GeometryBounds#

Members

Name	Type	Description
center	THREE.Vector3
radius	number
max	THREE.Vector3
min	THREE.Vector3

GeometryConfig#

disabled#

meshes#

Members

Name	Type	Description
meshes.wireframe	boolean
meshes.depthWrite	boolean

edges#

points#

GeometryData#

cache#

Members

Name	Type	Description
cache.dirtyStamp	number	The dirty stamp will be updated, as soon as a client side modification of the geometry will happen! Examples: 'setColor' or 'setOpacity' Can for example be used to trigger the render process for this container.

stamp#

bounds#

config#

Members

Name	Type	Description
config.product	Record<ObjectID, GeometryConfig>

GeometryApi#

updateBounds#

Updates the @see geometry.bounds depending on all products of the model. The update will only happen, if at least one solid of one product is available.

Declaration

(): void

Returns void

createGeometryIfNotCached#

Declaration

(containerId: ObjectID, color?: number[]): ContainerGeometryT | undefined

Params

Name	Type	Default	Description
containerId	ObjectID
color?	number[]

Returns ContainerGeometryT | undefined

setGraphicColor#

Declaration

(containerId: ObjectID, graphicId: GraphicID, r: number, g: number, b: number): void

Params

Name	Type	Default	Description
containerId	ObjectID
graphicId	GraphicID
r	number
g	number
b	number

Returns void

setContainerColor#

Declaration

(containerId: ObjectID, r: number, g: number, b: number): void

Params

Name	Type	Default	Description
containerId	ObjectID
r	number
g	number
b	number

Returns void

setOpacity#

Declaration

(containerId: ObjectID, opacity: number): void

Params

Name	Type	Default	Description
containerId	ObjectID
opacity	number

Returns void

setConfig#

Declaration

(objId: ObjectID, config: Partial<GeometryConfig> | null): void

Params

Name	Type	Default	Description
objId	ObjectID
config	Partial<GeometryConfig> l null

Returns void

findDecorated#

Declaration

(): GeometryElement[]

Returns GeometryElement[]

filter#

Declaration

(cb: (elem: GeometryElement) => boolean, options?: {
    onlyOne?: boolean;
    containerId?: ObjectID;
}): GeometryElement[]

Params

Name	Type	Default	Description
cb	(elem: GeometryElement) => boolean
options.onlyOne?	boolean
options.containerId?	ObjectID

Returns GeometryElement[]

geometryData#

cache#

stamp#

bounds#

center#

radius#

min#

max#

config#

product#

geometryApi#

BuerliScope#

SelectorID#

SeletedItemData#

SelectionScope#

SelectedItem#

id#

scope#

data#

label#

removeCondition#

Declaration

(d: DrawingState) => boolean

Params

Name	Type	Default	Description
d	DrawingState

Returns boolean

SelectionFilter#

Members

Name	Type	Description

CustomSelect#

Members

Name	Type	Description

Selector#

Type for selector.

Members

Name	Type	Description
isSelectable	SelectionFilter
items	Array<SelectedItem<T>>
hoveredItem	SelectedItem<T> l null
maxLen	number
customSelect	CustomSelect
customUnSelect	CustomSelect

SelectionData#

Members

Name	Type	Description
refs	Record<SelectorID, Selector>
active	SelectorID l null

SelectionApi#

unselectAll#

unselect#

select#

setHovered#

activateSelector#

createSelector#

areItemsSelected#

Declaration

(items: SelectedItem[], selectorId?: SelectorID): boolean

Params

Name	Type	Default	Description
items	SelectedItem[]
selectorId?	SelectorID

Returns boolean

isItemSelected#

Declaration

(item: SelectedItem, selectorId?: SelectorID): boolean

Params

Name	Type	Default	Description
item	SelectedItem
selectorId?	SelectorID

Returns boolean

setItems#

selectGraphic#

Declaration

(selectorId: SelectorID, items: {
    productId: ObjectID;
    containerId: GraphicID;
    graphicId?: GraphicID;
}[], options?: {
    unselectExisting?: boolean;
}): void

Params

Name	Type	Default	Description
selectorId	SelectorID
items	{ productId: ObjectID; containerId: GraphicID; graphicId?: GraphicID }[]
options.unselectExisting?	boolean

Returns void

getGraphicItem#

Declaration

(productId: ObjectID, containerId: GraphicID, graphicId?: GraphicID): SelectedItem<ProductElement> | null

Params

Name	Type	Default	Description
productId	ObjectID
containerId	GraphicID
graphicId?	GraphicID

Returns SelectedItem<ProductElement> | null

selectionData#

refs#

active#

selectionApi#

createGraphicItem#

PluginDescription#

name#

version#

author#

persistent#

global#

initialState#

Members

Name	Type	Description

Plugin#

Root#

Members

Name	Type	Description

View#

Members

Name	Type	Description

description#

PluginDef#

PluginImpl#

Members

Name	Type	Description

PluginID#

PluginState#

PluginData#

feature#

Contains ids of feature-plugins

global#

Contains ids of global-plugins

refs#

active#

Members

Name	Type	Description
active.feature	PluginID l null
active.global	PluginID[]

visible#

PluginApi#

setActiveFeature#

Declaration

(id: ObjectID | null): void

Params

Name	Type	Default	Description
id	ObjectID l null

Returns void

setVisiblePlugin#

Declaration

(id: PluginID, visible: boolean): void

Params

Name	Type	Default	Description
id	PluginID
visible	boolean

Returns void

setActiveGlobal#

Declaration

(id: PluginID, active: boolean): void

Params

Name	Type	Default	Description
id	PluginID
active	boolean

Returns void

createPlugin#

Declaration

(def: PluginDef, defaultId?: ObjectID | string, drawingId?: DrawingID, objectId?: ObjectID): (deactivate?: boolean) => void

Params

Name	Type	Default	Description
def	PluginDef
defaultId?	ObjectID l string
drawingId?	DrawingID
objectId?	ObjectID

Returns (deactivate?: boolean) => void

pluginData#

feature#

global#

refs#

active#

feature#

global#

visible#

pluginApi#

isPromisePlugin#

Declaration

export function isPromisePlugin(def: PluginDef): def is Promise<Plugin>;

Params

Name	Type	Default	Description
def	PluginDef

Returns def is Promise<Plugin>

InteractionData#

Members

Name	Type	Description
hovered	InteractionInfo l null
selected	InteractionInfo[]

InteractionApi#

setHovered#

Sets the hovered item in the store to the given item.

Declaration

(item: InteractionInfo | null): void

Params

Name	Type	Default	Description
item	InteractionInfo l null		The item.

Returns void

setSelected#

Reset the 'selected' array to the given items.

Declaration

(items: InteractionInfo[]): void

Params

Name	Type	Default	Description
items	InteractionInfo[]		The items.

Returns void

select#

Adds the given item to the 'selected' array if it is not yet selected. If the item is already selected, it will be removed from the 'selected' array.

With 'multi' enabled, the already selected items will remain selected.

Declaration

(item: InteractionInfo, multi?: boolean): void

Params

Name	Type	Default	Description
item	InteractionInfo		The item to select.
multi?	boolean		Do multi select.

Returns void
